High Precision Slant Bed CNC Lathe Machine With Imported Power Turret Power Head

SHENZHEN JOINT TECHNOLOGY CO.,LTD

High Precision Slant Bed CNC Lathe Machine With Imported Power Turret Power Head

Brand Name : JOINT

Model Number : HTC-5661MY

Certification : ISO 9001:2015

Place of Origin : CHINA

MOQ : 1 SET

Price : NEGOTIATION

Payment Terms : L/C, T/T

Supply Ability : 1000 SETS/YEAR

Delivery Time : NEGOTIATION

Packaging Details : WOODEN PALLTES / WOODEN CASE

Max swing diameter over bed (mm) : 560

Max processing diameter over slide : 190

Max processing length : 500/465/300(equipped with power tool turret)

Spindle form : A2-6(8'')/A2-8(10'')

Spindle motor rate : 11kw

Max spindle rotation speed : 4200/3000

Spindle hole diameter : 66/87

Bar diameter : 52/75

X axis travel : 230

Z axis travel : 610

Tool turret center height : 100

Tailstock sleeve diameter : 80

Tailstock sleeve travel : 80

Tailstock max travel : 450

Contact Now

High Precision Slant Bed CNC Lathe Machine With Imported Power Tool Turret Power Head


High Precision CNC Y Axis Metal Tool Lathe Turning Milling HTC-5661MY:
1. Equipped with imported power turret + power head and servo control, high precision automatic tool change, and radial and axial milling function.
2. Adopted multiple pipeline and big power coolant system, ensure the surface fineness of the turn-milling.
3. Spindle brake system, assured the accuracy of milling.
4. With Y axis power motor, realize side multi-position drilling hole or side milling groove, drilling hole etc function.



Parameters sheet:

ModelHTC-5661MY
Max. swing diameter over bedmm560
Max. swing diameter over carriagemm190
Max. length of workpiecemm500/465/300 (With Power tool turret)
Spindle head (Chuck optional) A2-6 (8")/ A2-8 (10")
Spindle motorkw11
Spindle rotation speedrpm4200/3000
Spindle through-hole diametermmΦ66/Φ87
Bar diametermmΦ52/Φ75
X axis limited travelmm230
Z axis limited travelmm610
Tool post 10T/12T servo tool turret
12T power tool turret
8T/10T/12T hydraulic tool turret
Height of tool turret centermm100
Diameter of tailstock sleevemm80
Trevel of tailstock sleevemm80
Max. travel of tailstockmm450
Tailstock sleeve taper MT4
Bed type and slant angle Whole body slant type 30°
Dimensionmm2550*1760*1900
Weightkg3200


Standard accessories:

1. GSK/SYNTEC/FANUC control system
2. Taiwan spindle 4200rpm, imported bearing
3. Linear guide rail
4. Taiwan 8'' hollow hydraulic chuck and oil cylinder
5. Hydraulic tailstock, hydraulic station
6. 12 positions power tool turret,
7. 2 Power heads+Y axis
8. 2 tool holders
9. Fully closed cover
10. Auto lubrication system
11. Cooling system
12. Hand unit
13. Working light
14. Manual tailstock
15. Technical documents
